Quick Details

  • Condition: New
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: TC
  • Model Number: TC-classic
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Working width: 1300mm
  • Working height: 900+/-20mm
  • Feed speed: 8-20m/min
  • Passing height: 3-100mm
  • based materials: Chipboards/MDF/HDF/Honeycomb boards/solid wood board/sandwich elements
  • Based material width: 200-1250mm
  • Based material length: 500-2450mm
  • Based material thickness: 3-100mm
  • Processing in sheets cut to size: Acrylic,PET PVC foils,HPL,CPL
  • Processing from the roll: PET, PVC foils, Paper foils

Packaging & Delivery

Packaging Details 1, Foam & shrink film
2, Wooden case should be added more cost
Delivery Time 35-40days after receiving the deposit

Product Description

High gloss laminating.Manufacture of lightboards,composite boards and insulation elements.

Features

Infeed transport track with cleaning and preheating unit.

Glue spreading machine for hot melt with thermal oil heated applying and doctor rollers(up to 160)

Automatic glue supply by a 200L drum melting device.

Lay-up belt with lay-up rack for the feed of material in longitudinal and transverse decoration.

Roller press with uncoiling station for material from the roll.

Outfeed transport.

Foshan TC Supply PVC laminating machines for plywood and MDF
Technical Data PUR Line
Working Width1300mm
Working Height900+20mm
Feed Speed8-20m/min
Passing Height3-100mm
Operating Sideright hand;on request left hand
Feed Of Boardson fix edge on the right

Substrate
Materialchipboards/MDF/HDF/Honeycomb boards
solid wood boards/sandwich elements
Width200-1250mm
Length500-2450mm
Thickness3-100mm

Surface Material
Processing in sheets cut sizeAcrylic,PET,PVC foils,HPL,CPL
Processing from the rollPET,PVC foils,Paper foils
ElasticitySurface material must be so elastic
that no splintering will occur during trimming

Glue
PURhot melt
Coating40-80g/m2



Our Services

Product Process



Packaging & Shipping

1. Foam & shrink film
2. Wooden case should be added more cost



Contact Information
Company Information



FOSHAN TC GROUP WOODWORKING MACHINERY CO., LTD

Established in 2006 and is located in the industrial city of China - Shunde District, Foshan City, Guangdong Province. The company specialized in the developing and producting woodworking - surface decoration machine mainly. It experienced in the adhesive, stickers, shaped cladding, and composite materialsm we can also tailor-made various shaped surface decoration machinery according to the requirement of customer.

Our company always carried for woard the honest and innovative spirit over the years. With the strong brand heritage, it satisfied the market demand, and focus on long-term development, providing the products with high quality and low price, stable and reliable. The perfect after- sales service system and products has won the majority of the customers all over the country.
